Hot Cutting Seam Integrated Machine
The integrated hot cutting and sewing machine is a highly efficient and intelligent device that combines hot cutting and sewing functions. By combining precise hot cutting technology with automated sewing processes, it can complete cutting, edge sealing, and sewing in one step, greatly improving production efficiency and product quality. It is an ideal choice for modern production.
RQF-800D woven bag thermal sewing all-in-one machine features:
·Electric automatic loading
• Manual correction (automatic optional)
• Color mark tracking, servo-controlled precise control of bag length and conveying
· Automatic hot cutting and splicing
• PLC centralized control, touch screen for setting, displaying, recording, storing, and recalling data.
• Variable frequency speed control, automatic adjustment for cutting, sewing, and printing
Automatic counting, bag stacking, and constant displacement.
• Free conversion between forward and reverse tracking
• The sewing machine automatically alarms if the thread breaks and stops.
• Flue gas recovery unit (optional)
Main technical parameters:
• Fabric unwinding diameter ≤Ø1400mm
• Bag cutting width ≤ 850mm
·Cut bag length ≥500-1300mm
• Cutting speed: 20-40 pcs/min
• Sewing stitch length: 5-14mm
• Bottom hem width: 16-30mm
Power: 8KW
